| TEM NUMBER | PRODUCT PART NUMBER | SUPPLY VOLTAGE (DC) | CONTACTS |
|---|---|---|---|
| 0060490 | RE5910/070 | 24 V | 3 N/O contacts |
| 0060491 | RE 5910/071 | 24 V | N/O contact, 1 NC contact
*The NC contact can only be used as |
| 0060621 | RE 5910/051 | ||
| 0059573 | RE 5910/040 | ||
| 0059654 | RE 5910/043 | ||
| 0060616 | RE 5910/010 | ||
| 0059653 | RE 5910/042 |
Harness RE 5910/071.
Metal clip to affix to belt.
Dimensions of holster (external) 46 x 78 x 143 mm
1/4 wavelength 433 – 434Mhz BNC Aerial
2 m and 5 m aerial extension cable lengths
Battery
Type Lithium-ion
Service life Min. 500 cycles (charge/discharge cycles)
Charging time 2 h, bei + 20 °C (80 %)
(for completely discharged battery)
Full charging time 2 h 30 min (100 %)
-Normal operation of
push buttons: 20 h, at 50 % operation and + 20 °C
-After 10 minutes charging
of discharged battery: approx. 1 h
Storage temperature: – 20 °C … + 50 °C
Charging temperature: 0 °C … + 40 °C
