| Attribute | Value |
|---|---|
| Secured Switch-off Distance Sar: | max. 17 mm(The assured release distance s_ar corresponds to the reset distance.) |
| Repeat Accuracy R: | max. 10 % |
| Rated insulation voltage Ui: | 26.4 V |
| Rated impulse withstand voltage Uimp: | 1.5 kV |
| Switching voltage: | 24 V |
| Switching current: | 8 … 500 mA |
| Switching characteristics: | NO + NC |
| Connection Type: | Hard-wired encapsulated cable with cable end sleeves 0.34 mm2 |
| Number of NO contacts: | 1 NO contacts |
| Tightening torque: | 0.4 … 0.5 Nm |
| Design: | E |
| Installation Orientation: | any |
| Cable length: | 5 m |
| Mechanical Life: | 100 x 10? |
| Shock And Vibration Resistance: | Acc. to EN IEC 60947-5-3 |
| Degree of protection: | IP67 |
| Ambient temperature: | -20 … +60 °C |
| Method of Operation: | magnetic, reed contact |
| in compliance with: | EN ISO 13849-12015; EN 501781997; EN 60204-12006/A12009; EN ISO 141192013; EN 61000-6-22005; EN 61000-6-32007/A12011; EN 60947-5-32013 |
| Ordernumber: | 85743 |
| Item designation: | CMS-R-EXM-05V |
| Gross weight: | 0,311kg |
| Customs tariff number: | 85389099990 |
| ECLASS: | 27-27-24-02 Safety-related magnetic proximity switch |
| Number NC contacts: | 1 NC contact |
